Siemens sinamics dcp - r0947[0...63] Fault number; Fault number; r0948[0...63] Fault time received in milliseconds; t_fault recv ms; r0949[0...63] Fault value; Fault value

SINAMICS DCP
List Manual (LH21), 05/2016
53
2 Parameters
2.2 List of parameters
Description: This parameter is identical to r0945.
Description: This parameter is identical to r0945.
Description: Displays the system runtime in milliseconds when the fault occurred.
Dependency: Refer to: r0945, r0947, r0949, r2109, r2114, r2130, r2133, r2136, r3115, r3120, r3122
Notice: The time comprises r2130 (days) and r0948 (milliseconds).
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault buffer and the assignment of the indices is shown in r0945.
When the parameter is read via PROFIdrive, the TimeDifference data type applies.
Description: Displays the system runtime in milliseconds when the fault occurred.
Dependency: Refer to: r0945, r0947, r0949, r2109, r2114, r2130, r2133, r2136, r3115, r3120, r3122
Notice: The time comprises r2130 (days) and r0948 (milliseconds).
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault buffer and the assignment of the indices is shown in r0945.
When the parameter is read via PROFIdrive, the TimeDifference data type applies.
Description: Displays additional information about the fault that occurred (as integer number).
Dependency: Refer to: r0945, r0947, r0948, r2109, r2130, r2133, r2136, r3115, r3120, r3122
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault buffer and the assignment of the indices is shown in r0945.
r0947[0...63] Fault number / Fault number
CU_DCP, DCP_CTRL Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
r0947[0...63] Fault number / Fault number
TM150, TM15DI_DO,
TM31
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: 8050, 8060
Min Max Factory setting
- - -
r0948[0...63] Fault time received in milliseconds / t_fault recv ms
CU_DCP, DCP_CTRL Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- [ms] - [ms] - [ms]
r0948[0...63] Fault time received in milliseconds / t_fault recv ms
TM150, TM15DI_DO,
TM31
Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: 8050, 8060
Min Max Factory setting
- [ms] - [ms] - [ms]
r0949[0...63] Fault value / Fault value
CU_DCP, DCP_CTRL Can be changed: - Access level: 3
Data type: Integer32 Func. diagram: 8060
Min Max Factory setting
- - -
