4 Faults and alarms
4.2 List of faults and alarms
SINAMICS DCP
464 List Manual (LH21), 05/2016
A35802 (F, N) TM: Time slice overflow
Drive object: DCP_CTRL, TM150, TM15DI_DO, TM31
Cause: A time slice overflow has occurred on the Terminal Module.
Remedy: Replace the Terminal Module.
A35803 (F, N) TM: Memory test
Drive object: DCP_CTRL, TM150, TM15DI_DO, TM31
Cause: An error has occurred during the memory test on the Terminal Module.
Remedy: - check whether the permissible ambient temperature for the Terminal Module is being maintained.
- replace the Terminal Module.
F35804 (N, A) TM: CRC
Drive object: DCP_CTRL, TM150, TM15DI_DO, TM31
Cause: A checksum error has occurred when reading-out the program memory on the Terminal Module.
Fault value (r0949, interpret hexadecimal):
Difference between the checksum at POWER ON and the actual checksum.
Remedy: - check whether the permissible ambient temperature for the component is maintained.
- replace the Terminal Module.
A35805 (F, N) TM: EEPROM checksum error
Drive object: DCP_CTRL, TM150, TM15DI_DO, TM31
Cause: Internal parameter data is corrupted.
Alarm value (r2124, interpret hexadecimal):
01: EEPROM access error.
02: Too many blocks in the EEPROM.
Remedy: - check whether the permissible ambient temperature for the component is maintained.
- replace the Terminal Module 31 (TM31).
A35807 (F, N) TM: Sequence control time monitoring
Drive object: DCP_CTRL, TM150, TM15DI_DO, TM31
Cause: Error, timeout, sequence control on the Terminal Module.
Remedy: Replace the Terminal Module.
F35820 TM DRIVE-CLiQ: Telegram error
Drive object: DCP_CTRL, TM150, TM15DI_DO, TM31
Cause: A DRIVE-CLiQ communication error has occurred from the Control Unit to the Terminal Module involved.
Fault cause:
1 (= 01 hex):
Checksum error (CRC error).
2 (= 02 hex):
Telegram is shorter than specified in the length byte or in the receive list.
3 (= 03 hex):
Telegram is longer than specified in the length byte or in the receive list.
4 (= 04 hex):
The length of the receive telegram does not match the receive list.
5 (= 05 hex):
The type of the receive telegram does not match the receive list.
6 (= 06 hex):
The address of the component in the telegram and in the receive list do not match.
7 (= 07 hex):
A SYNC telegram is expected - but the received telegram is not a SYNC telegram.
8 (= 08 hex):
No SYNC telegram is expected - but the received telegram is one.
9 (= 09 hex):
The error bit in the receive telegram is set.
