2 Parameters
2.2 List of parameters
SINAMICS DCP
260 List Manual (LH21), 05/2016
Description: Setting for starting the procedure to copy the diagnostics file to the memory card.
Value: 0: Inactive
1: Start copying
2: Copy file to User\Data folder
Description: Setting to reset the load data for a thyristor.
Value: 0: Do not reset data
1: Reset data
Index: [0] = Thyristor X11
[1] = Thyristor X12
[2] = Thyristor X13
[3] = Thyristor X14
[4] = Thyristor X15
[5] = Thyristor X16
[6] = Thyristor X21
[7] = Thyristor X22
[8] = Thyristor X23
[9] = Thyristor X24
[10] = Thyristor X25
[11] = Thyristor X26
Description: Sets message numbers for the diagnostics memory.
A trace is saved in the diagnostics file if one of these messages occurs.
Description: Sets the signal source for the signals to be recorded in the diagnostics memory.
Description: Display and connector output for the status of the trace.
In the least significant byte, the parameter value contains the status of trace 0 – and in the most significant byte, the
status of trace 1.
p50832 Diagnostics memory copy recorded file to memory card / Diag_mem copy file
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Integer16 Func. diagram: 8056
Min Max Factory setting
0 2 0
p50837[0...11] Reset thyristor load data / Reset ThyrLoadData
DCP_CTRL Can be changed: U, T Access level: 4
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 1 0
p50838[0...2] Diagnostics memory message number / Diag_mem msg_no
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Unsigned16 Func. diagram: 8056
Min Max Factory setting
60000 60999 60000
p50839[0...5] CI: Diagnostics memory trace signal source / Diag_mem tr s_src
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 8056
Min Max Factory setting
- - 0
r50850 CO: Trace status / Trace stat
DCP_CTRL Can be changed: - Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
