2 Parameters
2.2 List of parameters
SINAMICS DCP
162 List Manual (LH21), 05/2016
Description: Sets the first trigger threshold for trigger via tolerance band.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Only effective when p4710 = 4, 5.
Description: Sets the second trigger threshold for trigger via tolerance band
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Only effective when p4710 = 4, 5.
Description: Sets the bit mask for the bit mask trigger.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Only effective when p4710 = 6.
Description: Sets the trigger condition for bit mask trigger.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Only effective when p4710 = 6.
Description: Displays the trigger index in the trace buffer. The trigger event occurred at this point.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Only valid when p4705 = 4.
p4713[0...1] Trace tolerance band trigger threshold 1 / Trace trig thr 1
CU_DCP Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.00
p4714[0...1] Trace tolerance band trigger threshold 2 / Trace trig thr 2
CU_DCP Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.00
p4715[0...1] Trace bit mask trigger, bit mask / Trace trig mask
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0 4294967295 0
p4716[0...1] Trace bit mask trigger trigger condition / Trace Trig_cond
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0 4294967295 0
r4719[0...1] Trace trigger index / Trace Trig_index
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
