Siemens sinamics dcp - p50780[0...3] CUD digital input;output 4... 7 inversion; CUD DI;DO inv; p50781 BI: CUD digital input;output 4 signal source; CUD DI;DO 4 s_src; p50782 BI: CUD digital input;output 5 signal source; CUD DI;DO 5 s_src; p50783 BI: CUD digital input;output 6 signal source; CUD DI;DO 6 s_src

SINAMICS DCP
List Manual (LH21), 05/2016
255
2 Parameters
2.2 List of parameters
Description: Setting to invert the signal at digital input/output 4 ... 7 (DI/DO 4 ... DI/DO 7) of the CUD.
Value: 0: Not inverted
1: Inverted
Index: [0] = DI/DO 4 (X177.15)
[1] = DI/DO 5 (X177.16)
[2] = DI/DO 6 (X177.17)
[3] = DI/DO 7 (X177.18)
Dependency: The terminal must be set as an output (p50789[0...3] = 1).
Refer to: p50789
Note: DI/DO: bidirectional digital input/digital output
Description: Sets the signal source for digital input/output 4 (DI/DO 4, X177.15) on the CUD.
Dependency: The terminal must be set as an output (p50789[0] = 1).
Refer to: p50789
Note: DI/DO: bidirectional digital input/digital output
Description: Sets the signal source for digital input/output 5 (DI/DO 5, X177.16) on the CUD.
Dependency: The terminal must be set as an output (p50789[1] = 1).
Refer to: p50789
Note: DI/DO: bidirectional digital input/digital output
Description: Sets the signal source for digital input/output 6 (DI/DO 6, X177.17) on the CUD.
Dependency: The terminal must be set as an output (p50789[2] = 1).
Refer to: p50789
Note: DI/DO: bidirectional digital input/digital output
Description: Sets the signal source for digital input/output 7 (DI/DO 7, X177.18) on the CUD.
p50780[0...3] CUD digital input/output 4 ... 7 inversion / CUD DI/DO inv
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 2060, 2065
Min Max Factory setting
0 1 0
p50781 BI: CUD digital input/output 4 signal source / CUD DI/DO 4 s_src
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2060
Min Max Factory setting
- - 0
p50782 BI: CUD digital input/output 5 signal source / CUD DI/DO 5 s_src
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2060
Min Max Factory setting
- - 0
p50783 BI: CUD digital input/output 6 signal source / CUD DI/DO 6 s_src
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2065
Min Max Factory setting
- - 0
p50784 BI: CUD digital input/output 7 signal source / CUD DI/DO 7 s_src
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2065
Min Max Factory setting
- - 0
