SINAMICS DCP
List Manual (LH21), 05/2016
263
2 Parameters
2.2 List of parameters
Note: The counters are reset to 0 at POWER ON.
The counters restart at 0 after reaching a value of 65535 (overflow).
Description: Connector output with constant fixed value value 0 %.
Description: Connector output with constant fixed value value 100 %.
Description: Connector output with constant fixed value value 200 %.
Description: Connector output with constant fixed value value -100 %.
Description: Connector output with constant fixed value value -200 %.
Bit field: Bit Signal name 1 signal 0 signal FP
00 Abort acknowledge flag 1 0 9350
01 Write denied flag 1 0 9350
02 Wake-up flag 1 0 9350
03 Received msg lost flag 1 0 9350
04 Bus-off condition flag 1 0 9350
05 Error passive mode flag 1 0 9350
06 Warning level flag 1 0 9350
07 Form error flag 1 0 9350
08 Bit error flag 1 0 9350
09 Stuck at dominant bit 1 0 9350
10 CRC error 1 0 9350
11 Stuff bit error 1 0 9350
12 ACK error 1 0 9350
13 Bus-off status 1 0 9350
14 Error passive state 1 0 9350
15 Warning status 1 0 9350
r52000 CO: Fixed value 0 % / Fix val 0%
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
- [%] - [%] - [%]
r52001 CO: Fixed value 100 % / Fix val 100 %
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
- [%] - [%] - [%]
r52002 CO: Fixed value 200 % / Fix val 200 %
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
- [%] - [%] - [%]
r52003 CO: Fixed value -100 % / Fix val -100 %
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
- [%] - [%] - [%]
r52004 CO: Fixed value -200 % / Fix val -200 %
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
- [%] - [%] - [%]
