Siemens sinamics dcp - p50756 CUD analog output 1 signal processing; CUD AO 1 sig proc; p50757 CUD analog output 1 smoothing time constant; CUD AO 1 T; p50758 CUD analog output 1 scaling; CUD AO 1 scal; p50759 CUD analog output 1 offset; CUD AO 1 offs

2 Parameters
2.2 List of parameters
SINAMICS DCP
252 List Manual (LH21), 05/2016
Description: Sets the mode for signal processing at analog output 1 (AO 1, X177.51/52).
Value: 0: Signal not influenced
1: Signal absolute value generation
2: Signal inverted
3: Signal absolute value generation inverted
Note: AO: Analog Output
Description: Sets the time constant for smoothing the signal from analog output 1 (AO 1, X177.51/52).
Note: AO: Analog Output
Description: Sets the scaling for analog output 1 (AO 1, X177.51/52).
The value indicates the output value for mapping an input value of 100% at the analog output.
Note: AO: Analog Output
Description: Sets the offset for analog output 1 (AO 1, X177.51/52).
Note: AO: Analog Output
Description: Sets the delay time for digital input 0 (DI 0, X177.11) on the CUD.
Dependency: Refer to: r53010
Note: DI: Digital Input
Description: Sets the delay time for digital input 1 (DI 1, X177.12) on the CUD.
p50756 CUD analog output 1 signal processing / CUD AO 1 sig proc
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 2095
Min Max Factory setting
0 3 0
p50757 CUD analog output 1 smoothing time constant / CUD AO 1 T
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2095
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
p50758 CUD analog output 1 scaling / CUD AO 1 scal
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2095
Min Max Factory setting
-200.00 [V] 200.00 [V] 10.00 [V]
p50759 CUD analog output 1 offset / CUD AO 1 offs
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2095
Min Max Factory setting
-10.00 [V] 10.00 [V] 0.00 [V]
p50765 CUD digital input 0 delay time / CUD DI 0 t_del
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2050
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
p50766 CUD digital input 1 delay time / CUD DI 1 t_del
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2050
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
