SINAMICS DCP
List Manual (LH21), 05/2016
301
2 Parameters
2.2 List of parameters
Description: Display and connector output for the inner voltage on side 2.
Description: Display and connector output for the inner voltage on side 1.
Dependency: Refer to: p55515
Description: Display of the actual value for the inner voltage on side 2.
Dependency: Refer to: p55516
Description: Display and connector output for the sum of the reactor currents.
The value is the sum of r55511 and r55512.
Dependency: Refer to: r55511, r55512
Description: Display and connector output for the reactor current of power unit 1.
Dependency: Refer to: r55510
Description: Display and connector output for the reactor current of power unit 2.
Dependency: Refer to: r55510
r55506 CO: Actual value voltage inner side 2 / Act val U inner S2
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6818, 6850
Min Max Factory setting
- [%] - [%] - [%]
r55507 Actual value voltage inner side 1 / Act val U inner S1
DCP_CTRL Can be changed: - Access level: 1
Data type: FloatingPoint32 Func. diagram: 6850
Min Max Factory setting
- [V] - [V] - [V]
r55508 Actual value voltage inner side 2 / Act val U inner S2
DCP_CTRL Can be changed: - Access level: 1
Data type: FloatingPoint32 Func. diagram: 6850
Min Max Factory setting
- [V] - [V] - [V]
r55510 CO: Actual value reactor current sum / Act val I_re sum
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6850
Min Max Factory setting
- [%] - [%] - [%]
r55511 CO: Actual value reactor current power unit 1 / ActVal I_react PU1
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6850
Min Max Factory setting
- [%] - [%] - [%]
r55512 CO: Actual value reactor current power unit 2 / ActVal I_react PU2
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6850
Min Max Factory setting
- [%] - [%] - [%]
