Siemens sinamics dcp - p50734[0...3] BI: Fast analog inputs inversion; Fast AI inv; p50735[0...3] Fast analog inputs smoothing time constant; Fast AI T; p50736[0...3] BI: Signal source to enable fast analog inputs; Fast AI ena sig s; p50741[0...n] Analog input main actual value scaling; AI m act scal

SINAMICS DCP
List Manual (LH21), 05/2016
249
2 Parameters
2.2 List of parameters
Value: 0: Signal not influenced
1: Signal absolute value generation
2: Signal inverted
3: Signal absolute value generation inverted
Index: [0] = Select input 3 (X177.1/2)
[1] = Select input 4 (X177.3/4)
[2] = Select input 5 (X177.5/6)
[3] = Select input 6 (X177.7/8)
Note: AI: Analog Input
Description: Sets the signal source for inverting the signals for fast analog inputs "Select input 3 ... 6".
1 signal: inversion
0 signal: no inversion
Index: [0] = Select input 3 (X177.1/2)
[1] = Select input 4 (X177.3/4)
[2] = Select input 5 (X177.5/6)
[3] = Select input 6 (X177.7/8)
Note: AI: Analog Input
Description: Sets the time constant for smoothing the signals for fast analog inputs "Select input 3 ... 6".
Index: [0] = Select input 3 (X177.1/2)
[1] = Select input 4 (X177.3/4)
[2] = Select input 5 (X177.5/6)
[3] = Select input 6 (X177.7/8)
Note: AI: Analog Input
Description: Sets the signal source for enabling fast analog inputs "Select input 3 ... 6".
Index: [0] = Select input 3 (X177.1/2)
[1] = Select input 4 (X177.3/4)
[2] = Select input 5 (X177.5/6)
[3] = Select input 6 (X177.7/8)
Note: AI: Analog Input
Description: Sets the input voltage (8 - 270 V) for scaling to 100%.
Notice: This analog input cannot be externally accessed. It is reserved for subsequent use.
Note: AI: Analog Input
p50734[0...3] BI: Fast analog inputs inversion / Fast AI inv
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2085, 2090
Min Max Factory setting
- - 0
p50735[0...3] Fast analog inputs smoothing time constant / Fast AI T
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2085, 2090
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
p50736[0...3] BI: Signal source to enable fast analog inputs / Fast AI ena sig s
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2085, 2090
Min Max Factory setting
- - 1
p50741[0...n] Analog input main actual value scaling / AI m act scal
DCP_CTRL Can be changed: C2(1), U, T Access level: 4
Data type: FloatingPoint32 Func. diagram: 2075
Min Max Factory setting
-270.00 [V] 270.00 [V] 60.00 [V]
