Siemens sinamics dcp - r8858[0...39] COMM BOARD read diagnostics channel; CB diag_chan read; r8859[0...7] COMM BOARD identification data; CB ident data; r8860[0...62] CO: IF2 PZD receive double word; IF2 PZD recv DW

SINAMICS DCP
List Manual (LH21), 05/2016
199
2 Parameters
2.2 List of parameters
5: Non-cyclic communication
6: Cyclic communications but no setpoints (stop/no clock cycle)
255: Cyclic communication
Description: Displays the COMM BOARD diagnostics data.
Note: The display depends on the COMM BOARD being used.
Example for CBE20:
r8858[0] = 4201 --> Siemens CBE20
r8858[1] = 1 --> firmware type = PROFINET device (see p8835)
r8858[2] = x --> state of cyclic communication
r8858[3] = y --> state of the IP configuration
r8858[4] = 1281 --> device ID 0501 hex = SINAMICS S120/S150
r8858[5 ... 39] --> only for internal Siemens diagnostics.
Description: Displays the COMM BOARD identification data
Index: [0] = Version interface structure
[1] = Version interface driver
[2] = Company (Siemens = 42)
[3] = CB type
[4] = Firmware version
[5] = Firmware date (year)
[6] = Firmware date (day/month)
[7] = Firmware patch/hot fix
Note: Example for CBE20:
r8859[0] = 100 --> version of the interface structure V1.00
r8859[1] = 111 --> version of the interface driver V1.11
r8859[2] = 42 --> SIEMENS
r8859[3] = 0 --> CBE20
r8859[4] = 1200 --> first part, firmware version V12.00 (second part, see index 7)
r8859[5] = 2010 --> year 2010
r8859[6] = 2306 --> 23rd June
r8859[7] = 1300 --> second part, firmware version (complete version: V12.00.13.00)
Description: Connector output for interconnecting the PZD (setpoints) received via interface 2 in the double word format.
Index: [0] = PZD 1 + 2
[1] = PZD 2 + 3
[2] = PZD 3 + 4
[3] = PZD 4 + 5
[4] = PZD 5 + 6
[5] = PZD 6 + 7
[6] = PZD 7 + 8
r8858[0...39] COMM BOARD read diagnostics channel / CB diag_chan read
CU_DCP (PROFINET
CBE20)
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
r8859[0...7] COMM BOARD identification data / CB ident data
CU_DCP (PROFINET
CBE20)
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
r8860[0...62] CO: IF2 PZD receive double word / IF2 PZD recv DW
DCP_CTRL Can be changed: - Access level: 3
Data type: Integer32 Func. diagram: 2485, 9204,
9206
Min Max Factory setting
- - -
