SINAMICS DCP
List Manual (LH21), 05/2016
245
2 Parameters
2.2 List of parameters
Description: Sets the signal processing mode for analog input 0 (AI 0, X177.25/26) on the CUD.
Value: 0: Signal not influenced
1: Signal absolute value generation
2: Signal inverted
3: Signal absolute value generation inverted
Note: AI: Analog Input
Description: Sets the signal source for inverting the signal from analog input 0 (AI 0, X177.25/26) on the CUD.
1 signal: inversion
0 signal: no inversion
Note: AI: Analog Input
Description: Sets the time constant for smoothing the signal from analog input 0 (AI 0, X177.25/26) on the CUD.
Note: AI: Analog Input
Description: Sets the signal source to enable analog input 0 (AI 0, X177.25/26) on the CUD.
Note: AI: Analog Input
Description: Sets the type for analog input 1 (AI 1, X177.27/28) on the CUD.
Value: 0: Bipolar voltage input (-10 V ... +10 V)
1: Bipolar current input (-20 mA ... +20 mA)
2: Unipolar current input monitored (+4 mA ... +20 mA)
Note: AI: Analog Input
p50703 CUD analog input 0 signal processing / CUD AI 0 sig proc
DCP_CTRL Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: 2075
Min Max Factory setting
0 3 0
p50704 BI: CUD analog input 0 inversion / CUD AI 0 inv
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2075
Min Max Factory setting
- - 0
p50705 CUD analog input 0 smoothing time constant / CUD AI 0 T
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2075
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
p50706 BI: CUD analog input 0 signal source for enable / CUD AI 0 ena s_src
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2075
Min Max Factory setting
- - 1
p50710 CUD analog input 1 type / CUD AI 1 type
DCP_CTRL Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: 2080
Min Max Factory setting
0 2 0
