SINAMICS DCP
List Manual (LH21), 05/2016
265
2 Parameters
2.2 List of parameters
Description: Display and connector output for the "Main actual value" analog input (XT1.103/104).
Notice: This analog input cannot be externally accessed. It is reserved for subsequent use.
Note: AI: Analog Input
Description: Display and connector output for the raw value at the analog "Select input 1" (X177.27/28).
Note: AI: Analog Input
Description: Display and connector output for the analog "Select input 1" (X177.27/28).
Note: AI: Analog Input
Description: Display and connector output for the raw value at the analog "Select input 2" (X177.29/30).
Note: AI: Analog Input
Description: Display and connector output for the analog "Select input 2" (X177.29/30).
Note: AI: Analog Input
Description: Display and connector output for the raw value at analog input 3 (X177.1/2) on the CUD.
Dependency: Refer to: r52019
Note: AI: Analog Input
r52013 CO: CUD analog input main actual value / CUD AI m act
DCP_CTRL Can be changed: - Access level: 4
Data type: FloatingPoint32 Func. diagram: 2075
Min Max Factory setting
- [%] - [%] - [%]
r52014 CO: CUD analog input select input 1 raw value / CUD AI sel 1 raw
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
- [%] - [%] - [%]
r52015 CO: CUD analog input select input 1 / CUD AI sel 1
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
- [%] - [%] - [%]
r52016 CO: CUD analog input select input 2 raw value / CUD AI sel 2 raw
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
- [%] - [%] - [%]
r52017 CO: CUD analog input select input 2 / CUD AI sel 2
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
- [%] - [%] - [%]
r52018 CO: CUD analog input 3 raw value / CUD AI 3 raw
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2085
Min Max Factory setting
- [%] - [%] - [%]
