SINAMICS DCP
List Manual (LH21), 05/2016
241
2 Parameters
2.2 List of parameters
Description: Sets the delay time for monitoring the communication interfaces.
Monitoring power unit-related communication interfaces (parallel interface) after switching on the electronics power
supply are only active after the delay time set here has expired.
Note: Switching-on the electronics power supply of the components at different times prevents the interface monitoring
functions from responding.
Description: Sets fixed value 1.
This value is available at connector output r52401 for interconnection.
Dependency: Refer to: r52401
Description: Sets fixed value 2.
This value is available at connector output r52402 for interconnection.
Dependency: Refer to: r52402
Description: Sets fixed value 3.
This value is available at connector output r52403 for interconnection.
Dependency: Refer to: r52403
Description: Sets the signal level for fixed bit 0.
This value is available at binector output r53230.0 for interconnection.
Value: 0: Low
1: High
Dependency: Refer to: r53230
p50099 Communication monitoring delay time / Com mon t_del
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 9350
Min Max Factory setting
0.000 [s] 1000.000 [s] 30.000 [s]
p50401 Fixed value 1 / Fix val 1
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
p50402 Fixed value 2 / Fix val 2
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
p50403 Fixed value 3 / Fix val 3
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 3100
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
p50421 Fixed bit 0 / Fix bit 0
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 3100
Min Max Factory setting
0 1 0
