Siemens sinamics dcp - r8573[0...39] Macro Connector Inputs (CI) for torque setpoints; Macro CI M_set; r8585 Macro execution actual; Macro executed; p8805 Identification and maintenance 4 configuration; I&M 4 config; p8806[0...53] Identification and Maintenance 1; I&M 1

SINAMICS DCP
List Manual (LH21), 05/2016
191
2 Parameters
2.2 List of parameters
Description: Displays the ACX file saved in the appropriate directory in the non-volatile memory.
Dependency: Refer to: p1500
Note: For a value = 9999999, the following applies: The read operation is still running.
Description: Displays the macro currently being executed on the drive object.
Dependency: Refer to: p0015, p0700, p1000, p1500, r8570, r8571, r8572, r8573
Description: Sets the configuration for the content of identification and maintenance 4 (I&M 4, p8809).
Value: 0: Standard value for I&M 4 (p8809)
1: User value for I&M 4 (p8809)
Dependency: For p8805 = 0, if the user writes at least one value in p8809[0...53], then p8805 is automatically set to = 1.
When p8805 is reset = 0, then the content of the factory setting is set in p8809.
Note: Re p8805 = 0:
PROFINET I&M 4 (p8809) contains the information for the SI change tracking.
Re p8805 = 1:
PROFINET I&M 4 (p8809) contains the values written by the user.
Description: Parameters for the PROFINET data set "Identification and Maintenance 1" (I&M 1).
This information is known as "System identifier" and "Location identifier".
Dependency: Refer to: p8807, p8808
Notice: Only characters belonging to the standard ASCII character set may be used (32 dec to 126 dec).
Note: An ASCII table (excerpt) can be found, for example, in the appendix to the List Manual.
Re p8806[0...31]:
System identifier.
Re p8806[32...53]:
Location identifier.
r8573[0...39] Macro Connector Inputs (CI) for torque setpoints / Macro CI M_set
DCP_CTRL Can be changed: - Access level: 1
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
r8585 Macro execution actual / Macro executed
All objects Can be changed: - Access level: 1
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
p8805 Identification and maintenance 4 configuration / I&M 4 config
CU_DCP Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 1 0
p8806[0...53] Identification and Maintenance 1 / I&M 1
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
- -
