SINAMICS DCP
List Manual (LH21), 05/2016
133
2 Parameters
2.2 List of parameters
Description: Sets the signal source for terminal DI/DO 12 (X521.6) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.12 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 13 (X521.7) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.13 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 14 (X521.8) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.14 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 15 (X521.9) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.15 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the limit for the total output voltage of terminals X541.1, X541.2, X541.3 and X541.4 (DI/DO 8 ... 11) of Terminal
Module 31 (TM31).
Value: 0: 0.1 A total current limit DI/DO 8 ... 11
1: 1.0 A total current limit DI/DO 8 ... 11
Dependency: Refer to: p4028
Warning: Since the sum of the output currents at terminals X541.1, X541.2, X541.3 and X541.4 is limited, an overcurrent or
short circuit at one output terminal can cause a dip in the signal at the other terminals.
p4042 BI: TM15DI/DO signal source for terminal DI/DO 12 / TM15D s_srcDI/DO12
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9401
Min Max Factory setting
- - 0
p4043 BI: TM15DI/DO signal source for terminal DI/DO 13 / TM15D s_srcDI/DO13
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9401
Min Max Factory setting
- - 0
p4044 BI: TM15DI/DO signal source for terminal DI/DO 14 / TM15D s_srcDI/DO14
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9401
Min Max Factory setting
- - 0
p4045 BI: TM15DI/DO signal source for terminal DI/DO 15 / TM15D s_srcDI/DO15
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9401
Min Max Factory setting
- - 0
p4046 TM31 digital outputs limit current / TM31 DO limit curr
TM31 Can be changed: T Access level: 2
Data type: Integer16 Func. diagram: 9560
Min Max Factory setting
0 1 0
