SINAMICS DCP
List Manual (LH21), 05/2016
293
2 Parameters
2.2 List of parameters
Description: Sets the limiting for main current controller.
Description: Set the multiplier to evaluate the precontrol for the main current controller.
Description: Displays the current until the current in the individual power units is discontinuous
Description: Display and connector output for the control angle of power unit 1.
Description: Display and connector output for the control angle of power units 2 and 3.
Index 0:
Control angle of power unit 2.
Index 1:
Control angle of power unit 3.
Description: Display and connector output for the outputs of the differential current controller.
Index 0:
Correction value to symmetrize power units 1 and 2.
Index 1:
Correction value to symmetrize power units 1 and 3.
p55228 Main current controller limiting / Main ctrl limit
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6820
Min Max Factory setting
1.0 [%] 200.0 [%] 200.0 [%]
p55230 Main current controller precontrol multiplier / Mn ctr prctr fact
DCP_CTRL Can be changed: T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6820
Min Max Factory setting
0.0 [%] 100.0 [%] 98.0 [%]
r55235 Discontinuous limit / Discontinuous lim
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 6820
Min Max Factory setting
- [A] - [A] - [A]
r55250 CO: Power unit 1 control angle / PU1 ctrl_angle
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
- [%] - [%] - [%]
r55251[0...1] CO: Power units 2 and 3 control angle / PU 2 3 ctrl_angle
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
- [%] - [%] - [%]
r55252[0...1] CO: Differential current controller output / I_diff_ctrl_outp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
- [%] - [%] - [%]
