Siemens sinamics dcp - r0965 PROFIdrive profile number; PD profile number; p0969 System runtime relative; t_System relative; p0970 TM150 reset parameters; TM150 par reset

SINAMICS DCP
List Manual (LH21), 05/2016
55
2 Parameters
2.2 List of parameters
Index: [0] = Company (Siemens = 42)
[1] = Device type
[2] = Firmware version
[3] = Firmware date (year)
[4] = Firmware date (day/month)
[5] = Number of drive objects
[6] = Firmware patch/hot fix
Note: Example:
r0964[0] = 42 --> SIEMENS
r0964[1] = device type, see below
r0964[2] = 403 --> first part of the firmware version V04.03 (for second part, refer to index 6)
r0964[3] = 2010 --> year 2010
r0964[4] = 1705 --> 17th of May
r0964[5] = 2 --> 2 drive objects
r0964[6] = 200 --> second part, firmware version (complete version: V04.03.02.00)
Device type:
r0964[1] = 5490 --> SINAMICS DCM
Description: Displays the PROFIdrive profile number and profile version.
Constant value = 0329 hex.
Byte 1: Profile number = 03 hex = PROFIdrive profile
Byte 2: Profile version = 29 hex = Version 4.1
Note: When the parameter is read via PROFIdrive, the Octet String 2 data type applies.
Description: Displays the system runtime in ms since the last POWER ON.
Note: The value in p0969 can only be reset to 0.
The value overflows after approx. 49 days.
When the parameter is read via PROFIdrive, the TimeDifference data type applies.
Description: The parameter is used to initiate a reset of the parameters on Terminal Module 150 (TM150).
Value: 0: Inactive
1: Start a parameter reset
100: Start a BICO interconnection reset
Dependency: Refer to: p0010
Notice: After the value has been modified, no further parameter modifications can be made and the status is shown in r3996.
Modifications can be made again when r3996 = 0.
Note: A factory setting run can only be started if p0010 was first set to 30 (parameter reset).
At the end of the calculations, p0970 is automatically set to 0.
r0965 PROFIdrive profile number / PD profile number
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
p0969 System runtime relative / t_System relative
CU_DCP Can be changed: T Access level: 3
Data type: Unsigned32 Func. diagram: 8060
Min Max Factory setting
0 [ms] 4294967295 [ms] 0 [ms]
p0970 TM150 reset parameters / TM150 par reset
TM150 Can be changed: C2(30) Access level: 2
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 100 0
