SINAMICS DCP
List Manual (LH21), 05/2016
307
2 Parameters
2.2 List of parameters
Note: For bit 14:
There is either an overvoltage condition at side 1 or at side 2, or the electronics power supply signals an
undervoltage condition at the external 24 V power supply
Description: Sets the signal source for "acknowledge fault" of the power unit.
Description: Displays the voltage properties of the power unit.
Index: [0] = Minimum voltage
[1] = Rated voltage
[2] = Maximum voltage 1
[3] = Maximum voltage 2
[4] = Maximum voltage 3
[5] = Minimum voltage continuous
[6] = Voltage drop
Description: Displays the current properties of the power unit.
Index: [0] = Rated current
[1] = Current 1 reduced
[2] = Current 2 reduced
[3] = Current 3 reduced
Description: Displays the power properties of the power unit.
Description: Displays the clock frequency of the power unit.
14 Overvoltage condition or failure of the
electronics power supply
Yes No 6855
15 Overcurrent has occurred in power unit 3 Yes No 6855
p55551 BI: Power unit fault acknowledge signal source / PU F ackn s_src
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Unsigned32 / Binary Func. diagram: 6855
Min Max Factory setting
- - 2139.0
r55600[0...6] Power unit properties voltages / PU property U
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 6860
Min Max Factory setting
- [V] - [V] - [V]
r55601[0...3] Power unit properties currents / PU property I
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 6860
Min Max Factory setting
- [A] - [A] - [A]
r55602 Power unit properties power / PU property P
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 6860
Min Max Factory setting
- [kW] - [kW] - [kW]
r55603 Power unit properties frequency / PU property f
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 6860
Min Max Factory setting
- [kHz] - [kHz] - [kHz]
