SINAMICS DCP
List Manual (LH21), 05/2016
491
4 Faults and alarms
4.2 List of faults and alarms
F60094 (N, A) Power supply P15 overloaded
Drive object: DCP_CTRL
Cause: Power supply P15 (+15 V) at terminal X177.41 is overloaded.
Note:
r50047[1]: Temperature power unit 1 (in °C)
r50047[2]: Temperature power unit 2 (in °C)
r50047[3]: Temperature power supply module (in °C)
r50047[4]: Temperature mainboard module (in °C)
r50047[5]: Temperature CUD module (in °C)
r50047[6]: Air intake temperature (in °C)
r50047[7]: Reference voltage +10 V (in Volt)
r50047[8]: Reference voltage -10 V (in Volt)
r50047[9]: Temperature power unit 3 (in °C)
Remedy: Check the current load of the power supply P15 (X177.41).
F60096 (N, A) Temperature sensor faulty
Drive object: DCP_CTRL
Cause: A cable break or a short circuit has been detected for at least one temperature sensor.
Fault value (r0949, interpret decimal):
1: A cable break has occurred.
2: A short circuit has occurred.
Note:
r50047[1]: Incorrect sensor
0 = power unit 1
1 = power unit 2
2 = power supply module
3 = mainboard module
4 = CUD module
5 = air intake
6 = power unit 3
7 = external sensor
r50047[2]: Value of the analog-to-digital converter
Remedy: Send the device to an authorized repair shop.
F60097 (N, A) Power supply unit fault
Drive object: DCP_CTRL
Cause: The power supply unit in the SINAMICS DCP has a fault condition.
Note:
r50047[1]: Temperature power unit 1 (in °C)
r50047[2]: Temperature power unit 2 (in °C)
r50047[3]: Temperature power supply module (in °C)
r50047[4]: Temperature mainboard module (in °C)
r50047[5]: Temperature CUD module (in °C)
r50047[6]: Air intake temperature (in °C)
r50047[7]: Reference voltage +10 V (in Volt)
r50047[8]: Reference voltage -10 V (in Volt)
r50047[9]: Temperature power unit 3 (in °C)
Remedy: Carry out a POWER ON (switch-off/switch-on).
Note:
The device must be sent to an authorized repair shop if the problem still occurs after switching the electronics power
supply off and on again several times.
