SINAMICS DCP
List Manual (LH21), 05/2016
181
2 Parameters
2.2 List of parameters
The multiple trace is de-activated with a value = 0.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Refer to: r4841, p4844
Refer to: A02097, A02098
Notice: A multiple trace can have a negative impact on the total system performance.
From their inherent principle of operation, flash memory cards are subject to wear as a result of write operations. As
a consequence, the lifetime of flash memory cards is reduced when using the multiple trace functionality.
Description: Displays the currently running cycle (including deadtime) of the multiple trace.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Refer to: p4840, p4844
Description: Sets the number of ring buffer files for the measurement results of the multiple trace.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Refer to: p4840, r4841
Description: Displays the number of OA applications installed on this drive object.
Dependency: Refer to: r4951, r4952, r4955, p4956, r4957, r4958, r4959, r4960
Note: DO: Drive Object
OA: Open Architecture (OA application)
Description: Displays the total length of the identifiers of the OA applications installed on this drive object.
Dependency: Refer to: r4950, r4952, r4955, p4956, r4957, r4958, r4959, r4960
Note: The identifier of an OA application comprises a maximum of 8 characters plus separator.
Description: Displays the total length of the GUIDs of the OA applications installed on this drive object.
r4841[0...1] MTrace cycle actual display / Cycle act display
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
p4844[0...1] MTrace ring buffer files number / Ring buff file qty
CU_DCP Can be changed: T Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
5 5 5
r4950 OA DO-specific number / OA DO qty
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 16 -
r4951 OA DO-specific identifier total length / OA DO id tot_lgth
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 144 -
r4952 OA DO-specific GUID total length / OA DO GUID length
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 288 -
