SINAMICS DCP
List Manual (LH21), 05/2016
203
2 Parameters
2.2 List of parameters
[46] = PZD 47 + 48
[47] = PZD 48 + 49
[48] = PZD 49 + 50
[49] = PZD 50 + 51
[50] = PZD 51 + 52
[51] = PZD 52 + 53
[52] = PZD 53 + 54
[53] = PZD 54 + 55
[54] = PZD 55 + 56
[55] = PZD 56 + 57
[56] = PZD 57 + 58
[57] = PZD 58 + 59
[58] = PZD 59 + 60
[59] = PZD 60 + 61
[60] = PZD 61 + 62
[61] = PZD 62 + 63
[62] = PZD 63 + 64
Notice: A maximum of 4 indices of the "trace" function can be used.
Note: IF2: Interface 2
Description: Display for the maximum interconnected PZD in the receive/send direction
Index 0: receive (r8850, r8860)
Index 1: send (p8851, p8861)
Bit field: Bit Signal name 1 signal 0 signal FP
00 Bit 0 ON OFF -
01 Bit 1 ON OFF -
02 Bit 2 ON OFF -
03 Bit 3 ON OFF -
04 Bit 4 ON OFF -
05 Bit 5 ON OFF -
06 Bit 6 ON OFF -
07 Bit 7 ON OFF -
08 Bit 8 ON OFF -
09 Bit 9 ON OFF -
10 Bit 10 ON OFF -
11 Bit 11 ON OFF -
12 Bit 12 ON OFF -
13 Bit 13 ON OFF -
14 Bit 14 ON OFF -
15 Bit 15 ON OFF -
16 Bit 16 ON OFF -
17 Bit 17 ON OFF -
18 Bit 18 ON OFF -
19 Bit 19 ON OFF -
20 Bit 20 ON OFF -
21 Bit 21 ON OFF -
22 Bit 22 ON OFF -
23 Bit 23 ON OFF -
24 Bit 24 ON OFF -
25 Bit 25 ON OFF -
26 Bit 26 ON OFF -
27 Bit 27 ON OFF -
28 Bit 28 ON OFF -
29 Bit 29 ON OFF -
30 Bit 30 ON OFF -
31 Bit 31 ON OFF -
r8867[0...1] IF2 PZD maximum interconnected / IF2 PZDmaxIntercon
DCP_CTRL, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
