SINAMICS DCP
List Manual (LH21), 05/2016
405
4 Faults and alarms
4.2 List of faults and alarms
Remedy: The alarm automatically disappears again with the following actions:
- de-activate the drive object involved (p0105 = 0).
- de-activate the components involved (p0125 = 0, p0145 = 0, p0155 = 0, p0165 = 0).
- re-insert the components involved.
See also: p0105 (Activate/de-activate drive object)
A01316 Drive object inactive and again ready for operation
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: If, when inserting a component of the target topology, an inactive, non-operational drive object becomes operational
again. The associated parameter of the component is, in this case, set to "activate" (p0125, p0145, p0155, p0165).
Note:
This is the only message that is displayed for a de-activated drive object.
Remedy: The alarm automatically disappears again with the following actions:
- activate the drive object involved (p0105 = 1).
- again withdraw the components involved.
See also: p0105 (Activate/de-activate drive object)
A01317 (N) De-activated component again present
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: If a component of the target topology for an active drive object is inserted and the associated parameter of the
component is set to "de-activate" (p0125, p0145, p0155, p0165).
Note:
This is the only message that is displayed for a de-activated component.
Remedy: The alarm automatically disappears again with the following actions:
- activate the components involved (p0125 = 1, p0145 = 1, p0155 = 1, p0165 = 1).
- again withdraw the components involved.
A01318 BICO: De-activated interconnections present
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: This alarm is used in the following cases:
- If an inactive/non-operational drive object is active again/ready for operation
- If there are items in the list of BI/CI parameters (r9498[0...29], r9499[0...29])
- If the BICO interconnections saved in the list of BI/CI parameters (r9498[0...29], r9499[0...29]) have actually been
changed
Remedy: Reset alarm:
- Set p9496 to 1 or 2
or
- de-activate the drive object again.
A01319 Inserted component not initialized
Drive object: TM150, TM15DI_DO, TM31
Cause: Initialization is required for at least one inserted component.
This is only possible if the pulses are inhibited for all the drive objects.
Remedy: Activate pulse inhibit for all drive objects.
A01320 Topology: Drive object number does not exist in configuration
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: A drive object number is missing in p0978
Alarm value (r2124, interpret decimal):
Index of p0101 under which the missing drive object number can be determined.
Remedy: Set p0009 to 1 and change p0978:
Rules:
- p0978 must include all of the drive object numbers (p0101).
- it is not permissible for a drive object number to be repeated.
- by entering a 0, the drive objects with PZD are separated from those without PZD.
