2 Parameters
2.2 List of parameters
SINAMICS DCP
102 List Manual (LH21), 05/2016
Description: Number of alarms that have occurred after the last reset.
Dependency: When p2111 is set to 0, the following is initiated:
- all of the alarms of the alarm buffer that have gone [0...7] are transferred into the alarm history [8...63].
- the alarm buffer [0...7] is deleted.
Refer to: r2110, r2122, r2123, r2124, r2125
Note: The parameter is reset to 0 at POWER ON.
Description: Sets the signal source for external alarm 1.
Dependency: Refer to: A07850
Note: An external alarm is triggered with a 1/0 signal.
Description: Sets the signal source for external alarm 1.
Dependency: Refer to: A07850
Note: An external alarm is triggered with a 1/0 signal.
Description: Displays the total system runtime for the drive unit.
The time comprises r2114[0] (milliseconds) and r2114[1] (days).
After r2114[0] has reached a value of 86.400.000 ms (24 hours) this value is reset and r2114[1] is incremented.
Index: [0] = Milliseconds
[1] = Days
Dependency: Refer to: r0948, r2109, r2123, r2125, r2130, r2136, r2145, r2146
Note: The time in r2114 is used to display the times for faults and alarms.
When the electronic power supply is switched out, the counter values are saved.
After the drive unit is powered up, the counter continues to run with the last value that was saved.
Description: Sets the signal source for external alarm 2.
Dependency: Refer to: A07851
p2111 Alarm counter / Alarm counter
TM150, TM15DI_DO,
TM31
Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: 8050, 8065
Min Max Factory setting
0 65535 0
p2112 BI: External alarm 1 / External alarm 1
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: -
Min Max Factory setting
- - 1
p2112[0...n] BI: External alarm 1 / External alarm 1
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2546
Min Max Factory setting
- - 1
r2114[0...1] System runtime total / Sys runtime tot
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
p2116 BI: External alarm 2 / External alarm 2
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: -
Min Max Factory setting
- - 1
