SINAMICS DCP
List Manual (LH21), 05/2016
449
4 Faults and alarms
4.2 List of faults and alarms
Note:
In general, the copy protection can only be changed when know-how protection is deactivated.
KHP: Know-How Protection
See also: p3981 (Faults acknowledge drive object)
F13101 Know-how protection: Copy protection cannot be activated
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: An error occurred when attempting to activate the copy protection for the memory card.
Fault value (r0949, interpret decimal):
0: A memory card is not inserted.
Note:
KHP: Know-How Protection
Remedy: - insert the memory card and carry out POWER ON.
- Try to activate copy protection again (p7765).
F13102 Know-how protection: Consistency error of the protected data
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: An error was identified when checking the consistency of the protected files. As a consequence, the project on the
memory card cannot be run.
Fault value (r0949, interpret hexadecimal):
yyyyxxxx hex: yyyy = object number, xxxx = fault cause
xxxx = 1:
A file has a checksum error.
xxxx = 2:
The files are not consistent with one another.
xxxx = 3:
The project files, which were loaded into the file system via load (download from the memory card), are inconsistent.
Note:
KHP: Know-How Protection
Remedy: - Replace the project on the memory card or replace project files for download from the memory card.
- Restore the factory setting and download again.
F30051 Power unit: Motor holding brake short circuit detected
Drive object: DCP_CTRL
Cause: A short-circuit at the motor holding brake terminals has been detected.
Fault value (r0949, interpret decimal):
Only for internal Siemens troubleshooting.
Remedy: - check the motor holding brake for a short-circuit.
- check the connection and cable for the motor holding brake.
F30053 FPGA data faulty
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: The FPGA data of the power unit are faulty.
Remedy: Replace the power unit or update the FPGA data.
F30080 Power unit: Current increasing too quickly
Drive object: CU_DCP, TM150, TM15DI_DO, TM31
Cause: The power unit has detected an excessive rate of rise in the overvoltage range.
- closed-loop control is incorrectly parameterized.
- motor has a short-circuit or fault to ground (frame).
- U/f operation: Up ramp set too low.
- U/f operation: rated current of motor much greater than that of power unit.
- infeed: High discharge and post-charging currents for voltage dip.
- infeed: High post-charging currents for overload when motoring and DC link voltage dip.
- infeed: Short-circuit currents at power-up due to the missing line reactor.
- power cables are not correctly connected.
