SINAMICS DCP
List Manual (LH21), 05/2016
79
2 Parameters
2.2 List of parameters
Index: [0] = Clock synchronous mode activated
[1] = Bus cycle time (Tdp) [µs]
[2] = Master cycle time (Tmapc) [µs]
[3] = Instant of actual value acquisition (Ti) [µs]
[4] = Instant of setpoint acquisition (To) [µs]
[5] = Data exchange interval (Tdx) [µs]
[6] = PLL window (Tpll-w) [1/12 µs]
[7] = PLL delay time (Tpll-d) [1/12 µs]
Description: Displays how often the sign-of-life from the clock synchronous PROFIBUS/PROFINET controller last failed.
Description: Display for the maximum interconnected PZD in the receive/send direction
Index 0: receive (r2050, r2060)
Index 1: send (p2051, p2061)
Description: Sets the response for the receive value (r2090) after PZD failure.
Description: Displays the PROFIBUS address of the sender from which the process data (PZD) is received.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
[16] = PZD 17
[17] = PZD 18
r2065 PB/PN controller sign of life diagnostics / PB/PN ctr SoL diag
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
r2067[0...1] IF1 PZD maximum interconnected / IF1 PZDmaxIntercon
All objects Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
p2072 Response receive value after PZD failure / Resp aft PZD fail
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Unconditionally open holding brake (p0855) Freeze value Zero the value -
r2074[0...19] IF1 PROFIdrive diagnostics bus address PZD receive / IF1diag addr recv
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
