SINAMICS DCP
List Manual (LH21), 05/2016
281
2 Parameters
2.2 List of parameters
p54985 = 0:
--> the internal control for the LEDs is active.
p54985.x = 1 (x = 0...3):
--> the internal control for the two LEDs is not active.
--> the appropriate LED for diagnostics is switched on.
--> if both colors of an LED are switched on, then orange is output.
Description: Sets the address for the memory location of the EEPROM on the mainboard.
The memory location that can be written to is defined using the start address (p54990 = address) and the write
command (p54992 > 0 = number).
Dependency: Refer to: p54991, p54992, p54993, r54994
Description: Sets the write values for the EEPROM on the mainboard.
p54991[0]: The value is written to the memory location with p54990 = address.
p54991[1]: The value is written to the memory location with p54990 = address + 1.
...
p54991[31]: The value is written to the memory location with p54990 = address + 31.
Dependency: Refer to: p54990, p54992, p54993, r54994
Description: Setting for the write command to write to the EEPROM on the mainboard.
Procedure:
p54992 > 0 --> write operation is initiated.
Dependency: Refer to: p54990, p54991, p54993, r54994
Note: - the parameter value defines the number of bytes to be written.
- the address is set in p54990.
- the write values are set in p54991.
- the parameter is automatically set back to zero after the write operation has been completed.
Description: Sets the write protection for the EEPROM on the mainboard.
Bit field: Bit Signal name 1 signal 0 signal FP
00 LED H1000 green On Off 8055
01 LED H1000 red On Off 8055
02 LED H1010 green On Off 8055
03 LED H1010 red On Off 8055
p54990 Mainboard diagnostics EEPROM address / EEPROM address
DCP_CTRL Can be changed: U, T Access level: 4
Data type: Unsigned16 Func. diagram: 8055
Min Max Factory setting
0 32767 0
p54991[0...31] Mainboard diagnostics EEPROM write values / EEPROM write_vals
DCP_CTRL Can be changed: U, T Access level: 4
Data type: Unsigned8 Func. diagram: 8055
Min Max Factory setting
0 255 0
p54992 Mainboard diagnostics EEPROM write command / EEPROM write_cmd
DCP_CTRL Can be changed: U, T Access level: 4
Data type: Unsigned8 Func. diagram: 8055
Min Max Factory setting
0 32 0
p54993 Mainboard diagnostics EEPROM write protection / EEPROM write_prot
DCP_CTRL Can be changed: U, T Access level: 4
Data type: Integer16 Func. diagram: 8055
Min Max Factory setting
0 1 1
