SINAMICS DCP
List Manual (LH21), 05/2016
273
2 Parameters
2.2 List of parameters
Description: Sets the signal source for the "undervoltage limited reached" signal of the MPP tracker.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Sets the signal source for the "enable" signal of the MPP tracker.
BI: p54014[0, 1] = 1 signal:
- the MPP tracker is enabled.
BI: p54014[0, 1] = 0 signal:
- the MPP tracker is inhibited.
BI: p54014[2, 3] = 1 signal:
- the MPP tracker is inhibited.
BI: p54014[2, 3] = 0 signal:
- the MPP tracker is enabled.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Display and connector output for the smoothed actual power.
Dependency: Refer to: p54010, p54011
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Display and connector output for the output of the MPP tracker.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Display and connector output for the output of the MPP tracker after manual/automatic switchover.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
p54013 BI: MPP tracker lower voltage threshold reached signal source / MPPT U_min rch s_s
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / Binary Func. diagram: 6700
Min Max Factory setting
- - 55125.11
p54014[0...3] BI: MPP tracker enable signal source / MPPT enable s_src
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / Binary Func. diagram: 6700
Min Max Factory setting
- - [0] 899.11
[1] 1
[2] 55125.7
[3] 0
r54015 CO: MPP tracker actual power smoothed / MPPT act P smooth
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
- [%] - [%] - [%]
r54020 CO: MPP tracker output / MPPT outp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
- [%] - [%] - [%]
r54021 CO: MPP tracker output total / MPPT outp total
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
- [%] - [%] - [%]
