SINAMICS DCP
List Manual (LH21), 05/2016
33
2 Parameters
2.2 List of parameters
Description: The application-specific view of an existing drive object is entered into each index.
The parameter cannot be changed.
Dependency: Refer to: p0107, r0107
Note: The application-specific views are defined in files on the memory card with the following structure:
PDxxxyyy.ACX
xxx: Application-specific view (p0103)
yyy: Type of drive object (p0107)
Example:
PD052017.ACX
--> "017" stands for the drive object of type DC_CTRL
--> "052" is the number of the view for this drive object
Description: Displays the application-specific view of the individual drive object.
Dependency: Refer to: p0107, r0107
Description: Setting to activate/de-activate a drive object.
Value: 0: De-activate drive object
1: Activate drive object
Dependency: Refer to: r0106
Notice: The following applies when activating:
If components are inserted for the first time and the appropriate drive object is activated, then the drive system is
automatically booted. To do this, the pulses of all of the drive objects must be suppressed.
Description: Setting to activate/de-activate a drive object.
Value: 0: De-activate drive object
1: Activate drive object
2: Drive object de-activate and not present
Recommendation: After inserting all of the components of a drive object, before activating, first wait for Alarm A01316.
Dependency: Refer to: r0106
Refer to: A01316
Notice: The following applies when activating:
If components are inserted for the first time and the appropriate drive object is activated, then the drive system is
automatically booted. To do this, the pulses of all of the drive objects must be suppressed.
p0103[0...n] Application-specific view / Appl_spec view
CU_DCP Can be changed: C1(2) Access level: 2
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 999 0
r0103 Application-specific view / Appl_spec view
DCP_CTRL Can be changed: - Access level: 2
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 65535 -
p0105 Activate/de-activate drive object / DO act/deact
CU_DCP Can be changed: U, T Access level: 2
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 1 1
p0105 Activate/de-activate drive object / DO act/deact
DCP_CTRL Can be changed: T Access level: 2
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 2 1
