SINAMICS DCP
List Manual (LH21), 05/2016
237
2 Parameters
2.2 List of parameters
Description: Displays the calculated DRIVE-CLiQ bandwidth load based on the existing target topology.
The values are not made available until the RUNUP READY (800) state is adopted (see p3988).
Index 0 ... 7 corresponds to DRIVE-CLiQ socket X100 ... X107.
Dependency: Refer to: F01340
Description: Displays the calculated DRIVE-CLiQ DPRAM load based on the existing target topology.
The values are not made available until the RUNUP READY (800) state is adopted (see p3988).
Index 0 ... 7 corresponds to DRIVE-CLiQ socket X100 ... X107.
Dependency: Refer to: F01340
Description: The meaning of the parameter differs for reading and writing.
Read:
- Returns the number of memory areas monitored.
Write:
- Memory usage of a drive object: Enter drive object number
- Memory usage of the complete system: Enter value 65535
Description: Displays the memory usage for each drive object as actual value.
Index: [0] = Fast Memory 1
[1] = Fast Memory 2
[2] = Fast Memory 3
[3] = Fast Memory 4
[4] = Heap
Description: Displays the memory usage for each drive object as reference value.
r9987[0...7] DRIVE-CLiQ bandwidth load / DQ bandw load
CU_DCP Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
- [%] - [%] - [%]
r9988[0...7] DRIVE-CLiQ DPRAM load / DQ DPRAM load
CU_DCP Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
- [%] - [%] - [%]
p9990 DO memory usage actual value determination selection / Mem_use ActVal sel
CU_DCP Can be changed: U, T Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 65535 0
r9991[0...4] Memory usage drive object actual value / Mem_use DO ActVal
CU_DCP Can be changed: - Access level: 4
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
r9992[0...4] Memory usage drive object reference value / Mem_use DO ref val
CU_DCP Can be changed: - Access level: 4
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
