SINAMICS DCP
List Manual (LH21), 05/2016
277
2 Parameters
2.2 List of parameters
Description: Sets the droop for the voltage controller.
Description: Display and connector output for the actual value of the voltage controller.
Description: Display and connector output for the P component of the voltage controller.
Description: Display and connector output for the I component of the voltage controller.
Description: Display and BICO output for the state of the voltage controller.
Description: Sets the signal source for the positive current limit of the voltage controller.
p54127 Voltage controller droop / U_ctrl droop
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6818
Min Max Factory setting
0.00 [%] 20.00 [%] 0.00 [%]
r54130 CO: Voltage controller actual value / U_ctrl act val
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6818
Min Max Factory setting
- [%] - [%] - [%]
r54131 CO: Voltage controller P component display / U_ctrl Kp disp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6818
Min Max Factory setting
- [%] - [%] - [%]
r54132 CO: Voltage controller I component display / U_ctrl I-comp disp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6818
Min Max Factory setting
- [%] - [%] - [%]
r54135.0...2 CO/BO: Voltage controller state / U_ctrl state
DCP_CTRL Can be changed: - Access level: 2
Data type: Unsigned16 Func. diagram: 6818
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Voltage controller has reached its limit Yes No 6818
01 Voltage actual value is within the dead
range
Yes No 6818
02 Voltage controller is enabled. Yes No 6818
p54141 CI: Voltage controller positive current limit signal source / U_ctr I_lim posS_s
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6818
Min Max Factory setting
- - 52002[0]
