SINAMICS DCP
List Manual (LH21), 05/2016
271
2 Parameters
2.2 List of parameters
Description: Sets the signal source for the current setpoint for manual operation.
Manual operation is selected via binector input p54001 = 0 signal.
Dependency: Refer to: p54001
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Sets the signal source for switching over between manual and automatic operation.
BI: p54001 = 1 signal:
Automatic operation is selected.
BI: p54001 = 0 signal:
Manual operation is selected.
Dependency: Refer to: p54000
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Sets the signal source for the current limit of the MPP tracker.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Sets the signal source for the start value of the MPP tracker current.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
Description: Sets the search interval for the MPP tracker.
In this time interval, the MPP tracker changes the current setpoint in order to identify the point with the maximum
power.
Note: MPP: maximum power point (point along the characteristic with the maximum power)
p54000 CI: MPP tracker current setpoint manual signal source / MPPT I_s man s_src
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
- - 2050[1]
p54001 BI: MPP tracker manual/automatic signal source / MPPT man/aut s_src
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / Binary Func. diagram: 6700
Min Max Factory setting
- - 1
p54002 CI: MPP tracker current limit signal source / MPPT I_limit s_src
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
- - 1
p54003 CI: MPP tracker current start value signal source / MPPT I stVal s_src
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
- - 55112[0]
p54005 MPP tracker search interval / MPPT srch interv
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6700
Min Max Factory setting
0.10 [s] 100.00 [s] 2.00 [s]
