Siemens sinamics dcp - p55260 Differential current controller integrating time; I_diff_ctrl t_int; p55262 Differential current controller limiting; I_diff_ctrl limit; p55270 Closed-loop control mode; Cl­loop ctrl_mode; p55305 Modulator control angle limiting positive; Mod ctrAng lim pos

2 Parameters
2.2 List of parameters
SINAMICS DCP
294 List Manual (LH21), 05/2016
Description: Sets the integrating time for the differential current controller
Description: Sets the limiting for the differential current controller.
Description: Sets the operating mode for the closed-loop control.
Value: 0: Closed-loop controlled operation
1: Directly controlled PWM
Note: Setting p55270 = 1 is only for internal Siemens testing.
Description: Sets the positive limiting for the control angle.
In conjunction with p55306, it is possible to restrict the operating range of the SINAMICS DCP.
Dependency: Refer to: p55306
Note: Examples:
Control angle limited to:
0 ... +200 %: only positive current possible
-200 ... 0 %: only negative current possible
-100 ... +100 %: only step-down possible
Description: Sets the negative limiting for the control angle.
In conjunction with p55305, it is possible to restrict the operating range of the SINAMICS DCP.
Dependency: Refer to: p55305
Note: Examples:
Control angle limited to:
0 ... +200 %: only positive current possible
-200 ... 0 %: only negative current possible
-100 ... +100 %: only step-down possible
p55260 Differential current controller integrating time / I_diff_ctrl t_int
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
0.001 [s] 5000.000 [s] 100.000 [s]
p55262 Differential current controller limiting / I_diff_ctrl limit
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
0.000 [%] 50.000 [%] 10.000 [%]
p55270 Closed-loop control mode / Cl-loop ctrl_mode
DCP_CTRL Can be changed: T Access level: 2
Data type: Integer16 Func. diagram: 6825
Min Max Factory setting
0 1 0
p55305 Modulator control angle limiting positive / Mod ctrAng lim pos
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
0.00 [%] 200.00 [%] 200.00 [%]
p55306 Modulator control angle limiting negative / Mod ctrAng lim neg
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6825
Min Max Factory setting
-200.00 [%] 0.00 [%] -200.00 [%]
