SINAMICS DCP
List Manual (LH21), 05/2016
143
2 Parameters
2.2 List of parameters
Note: Prerequisite: The DI/DO must be set as an output (p4028.18 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 19 (X522.5) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.19 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 20 (X522.6) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.20 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 21 (X522.7) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.21 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 22 (X522.8) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.22 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 23 (X522.9) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.23 = 1).
DI/DO: Bidirectional Digital Input/Output
p4089 BI: TM15DI/DO signal source for terminal DI/DO 19 / TM15D s_srcDI/DO19
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9402
Min Max Factory setting
- - 0
p4090 BI: TM15DI/DO signal source for terminal DI/DO 20 / TM15D S_srcDI/DO20
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9402
Min Max Factory setting
- - 0
p4091 BI: TM15DI/DO signal source for terminal DI/DO 21 / TM15D S_srcDI/DO21
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9402
Min Max Factory setting
- - 0
p4092 BI: TM15DI/DO signal source for terminal DI/DO 22 / TM15D S_srcDI/DO22
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9402
Min Max Factory setting
- - 0
p4093 BI: TM15DI/DO signal source for terminal DI/DO 23 / TM15D S_srcDI/DO23
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9402
Min Max Factory setting
- - 0
