Siemens sinamics dcp - r2074[0...4] IF1 PROFIdrive diagnostics bus address PZD receive; IF1 diag addr recv; r2075[0...19] IF1 PROFIdrive diagnostics telegram offset PZD receive; IF1 diag offs recv

SINAMICS DCP
List Manual (LH21), 05/2016
81
2 Parameters
2.2 List of parameters
[50] = PZD 51
[51] = PZD 52
[52] = PZD 53
[53] = PZD 54
[54] = PZD 55
[55] = PZD 56
[56] = PZD 57
[57] = PZD 58
[58] = PZD 59
[59] = PZD 60
[60] = PZD 61
[61] = PZD 62
[62] = PZD 63
[63] = PZD 64
Note: IF1: Interface 1
Value range:
0 - 125: Bus address of the sender
65535: Not assigned
Description: Displays the PROFIBUS address of the sender from which the process data (PZD) is received.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
Note: IF1: Interface 1
Value range:
0 - 125: Bus address of the sender
65535: Not assigned
Description: Displays the PZD byte offset in the PROFIdrive receive telegram (controller output).
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
[16] = PZD 17
[17] = PZD 18
r2074[0...4] IF1 PROFIdrive diagnostics bus address PZD receive / IF1diag addr recv
TM150, TM15DI_DO,
TM31
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
r2075[0...19] IF1 PROFIdrive diagnostics telegram offset PZD receive / IF1 diag offs recv
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: 2410
Min Max Factory setting
- - -
