Siemens sinamics dcp - p2051[0...4] CI: IF1 PROFIdrive PZD send word; IF1 PZD send word; r2053[0...24] IF1 PROFIdrive diagnostics PZD send word; IF1 diag send word

SINAMICS DCP
List Manual (LH21), 05/2016
71
2 Parameters
2.2 List of parameters
[56] = PZD 57
[57] = PZD 58
[58] = PZD 59
[59] = PZD 60
[60] = PZD 61
[61] = PZD 62
[62] = PZD 63
[63] = PZD 64
Dependency: Refer to: p2061
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: IF1: Interface 1
Description: Selects the PZD (actual values) with word format to be sent to the fieldbus controller.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: IF1: Interface 1
Description: Displays the PZD (actual values) with word format sent to the fieldbus controller.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
[16] = PZD 17
[17] = PZD 18
[18] = PZD 19
[19] = PZD 20
[20] = PZD 21
[21] = PZD 22
[22] = PZD 23
[23] = PZD 24
[24] = PZD 25
p2051[0...4] CI: IF1 PROFIdrive PZD send word / IF1 PZD send word
TM150, TM15DI_DO,
TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Integer16 Func. diagram: -
Min Max Factory setting
- - 0
r2053[0...24] IF1 PROFIdrive diagnostics PZD send word / IF1 diag send word
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: 2483
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Bit 0 ON OFF -
01 Bit 1 ON OFF -
