SINAMICS DCP
List Manual (LH21), 05/2016
227
2 Parameters
2.2 List of parameters
Description: Displays the signal source list (Binector Output/Connector Output, BO/CO) for the first interconnections between this
drive and other drives/drive objects.
Dependency: Refer to: r9490, r9491, p9493
Notice: A drive cannot be deleted if this list is not empty!
Otherwise, another drive would continue to attempt to read a signal from a drive that no longer existed.
Note: All indices of r9491 to p9493 designate the same interconnection.
r9491[x] contains the signal receiver and r9492[x] the matching signal source; p9493[x] can be set to modify the
interconnection.
Description: Setting to reset the BICO interconnections to other drives.
Each interconnection can be individually reset.
Value: 0: Set connection to 0
1: Set connection to 1 (100 %)
2: Set connection to factory setting
15: Finished
Dependency: Refer to: r9490, r9491, r9492
Note: All indices of r9491 to p9493 designate the same interconnection.
r9491[x] contains the signal receiver and r9492[x] the matching signal source; p9493[x] can be set to modify the
interconnection.
Description: Sets the behavior for BICO interconnections to drive objects that are either not capable of operation or have been
deactivated.
BO/CO parameters are on the drive object that is either not capable of operation or has been deactivated (signal
source).
Value: 0: Inactive
1: Save interconnections
2: Save interconnections and establish the factory setting
Dependency: Refer to: p9496, p9497, p9498, p9499
Refer to: A01318, A01507
Note: For p9495 = 0, the following applies:
- the number of interconnections is zero (p9497 = 0).
For p9495 not equal to 0, the following applies:
- the BI/CI parameters involved are listed in p9498[0...29] (signal sink).
- the associated BO/CO parameters are listed in p9499[0...29] (signal source).
r9492[0...9] BO/CO of BICO interconnections to other drives / BO/CO to drive
All objects Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
p9493[0...9] Reset BICO interconnections to other drives / Reset BICO to drv
All objects Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 15 15
p9495 BICO behavior for de-activated drive objects / Behav for deact DO
All objects Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 2 0
