SINAMICS DCP
List Manual (LH21), 05/2016
291
2 Parameters
2.2 List of parameters
Description: Sets the signal source for the dynamic voltage limiting on side 1.
Description: Sets the range of the dynamic voltage limiting on side 1.
Description: Sets the threshold value for the overvoltage on side 1.
Above this voltage, the power unit pulses are inhibited.
Description: Sets the signal source for the dynamic voltage limiting on side 2.
Description: Sets the range of the dynamic voltage limiting on side 2.
Description: Sets the threshold value for the overvoltage on side 2.
Above this voltage, the power unit pulses are inhibited.
Description: Display and connector output for the PI output of the main current controller.
p55180 CI: Limiting side 1 U dyn signal source / Lim S1 U dyn s_src
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
- - 52002[0]
p55181 Limiting side 1 U dyn delta U / Lim S1 U dyn dU
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
0.10 [V] 400.00 [V] 10.00 [V]
p55182 Limiting side 1 overvoltage dynamic / Lim S1 U_over dyn
DCP_CTRL Can be changed: U, T Access level: 1
Data type: FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
0 [V] 1500 [V] 1000 [V]
p55185 CI: Limiting side 2 U dyn signal source / Lim S2 U dyn s_src
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
- - 52002[0]
p55186 Limiting side 2 U dyn delta U / Lim S2 U dyn dU
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
0.10 [V] 400.00 [V] 10.00 [V]
p55187 Limiting side 2 overvoltage dynamic / Lim S2 U_over dyn
DCP_CTRL Can be changed: U, T Access level: 1
Data type: FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
0 [V] 1500 [V] 1000 [V]
r55201 CO: Main current controller PI output / Main ctrl PI outp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6820
Min Max Factory setting
- [%] - [%] - [%]
