SINAMICS DCP
List Manual (LH21), 05/2016
283
2 Parameters
2.2 List of parameters
If value = 12:
The current at side 2 is specified as setpoint.
If U1 <= U2: reactor current setpoint = setpoint * U2/U1
If U1 > U2: reactor current setpoint = setpoint (no conversion)
If value = 20:
The power is specified as setpoint.
If U1 <= U2: reactor current setpoint = setpoint/U1
If U1 > U2: reactor current setpoint = setpoint/U2
Explanation:
U1: voltage at side 1
U2: voltage at side 2
All values are referred to rated device quantities (rated current, rated voltage, rated power).
Description: Sets the delay time for the current direction change.
The delay time is started when the sign changes at the ramp-function generator output.
A current setpoint of zero is entered while the delay time is running.
Description: Display and connector output for the current setpoint after the ramp-function generator.
Description: Display and connector output for the current setpoint in the reactor.
Description: Display and connector output for the current setpoint after suppressing low setpoints.
Description: Display and connector output for the current setpoint after the correction current controller.
p55065 Current setpoint sign delay time / I_set sign t_del
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6805
Min Max Factory setting
0.250 [ms] 1000.000 [ms] 100.000 [ms]
r55070 CO: Current setpoint after the ramp-function generator / I_set after RFG
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6805
Min Max Factory setting
- [%] - [%] - [%]
r55071 CO: Current setpoint reactor / I_set reactor
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6806
Min Max Factory setting
- [%] - [%] - [%]
r55072 CO: Current setpoint after limiting to the minimum / I_set aft lim min
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6805
Min Max Factory setting
- [%] - [%] - [%]
r55073 CO: Current setpoint corrected / I_set corrected
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6806
Min Max Factory setting
- [%] - [%] - [%]
