SINAMICS DCP
List Manual (LH21), 05/2016
173
2 Parameters
2.2 List of parameters
Description: Sets the physical address for the fourth signal to be traced.
The data type is defined using p4733.
Index: [0] = Trace 0
[1] = Trace 1
Description: Sets the physical address for the fifth signal to be traced.
The data type is defined using p4734.
Index: [0] = Trace 0
[1] = Trace 1
Description: Sets the physical address for the sixth signal to be traced.
The data type is defined using p4735.
Index: [0] = Trace 0
[1] = Trace 1
Description: Sets the physical address for the seventh signal to be traced.
The data type is defined using p4736.
Index: [0] = Trace 0
[1] = Trace 1
Description: Sets the physical address for the eighth signal to be traced.
The data type is defined using p4737.
Index: [0] = Trace 0
[1] = Trace 1
p4783[0...1] Trace physical address signal 3 / Trace PhyAddr Sig3
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0000 bin 1111 1111 1111 1111 1111 1111
1111 1111 bin
0000 bin
p4784[0...1] Trace physical address signal 4 / Trace PhyAddr Sig4
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0000 bin 1111 1111 1111 1111 1111 1111
1111 1111 bin
0000 bin
p4785[0...1] Trace physical address signal 5 / Trace PhyAddr Sig5
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0000 bin 1111 1111 1111 1111 1111 1111
1111 1111 bin
0000 bin
p4786[0...1] Trace physical address signal 6 / Trace PhyAddr Sig6
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0000 bin 1111 1111 1111 1111 1111 1111
1111 1111 bin
0000 bin
p4787[0...1] Trace physical address signal 7 / Trace PhyAddr Sig7
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0000 bin 1111 1111 1111 1111 1111 1111
1111 1111 bin
0000 bin
