SINAMICS DCP
List Manual (LH21), 05/2016
221
2 Parameters
2.2 List of parameters
Re index 2:
7: Name (r9208)
8: Component type (r9207)
9: Number of DRIVE-CLiQ connections (r9207)
11: Manufacturer (upper byte) and version (lower byte) (r9207)
12: Serial number (r9208)
13: Index (r9207)
15: Comparison level (r9207)
23: Order number (r9207)
24: Hardware serial number (r9208)
25: Collective order number (r9207)
28: Firmware version (r9207)
29: EEPROM version (r9207)
30: Hardware version (r9207)
1000: Name of DRIVE-CLiQ connection 0 (r9208)
1001: Name of DRIVE-CLiQ connection 1 (r9208)
...
1015: Name of DRIVE-CLiQ connection 15 (r9208)
Index: [0] = Actual topology/target topology
[1] = Component number
[2] = Identifier/property
Dependency: Refer to: r9207, r9208
Description: Displays the value for the property set in p9206.
A value is only displayed for integer type properties.
Dependency: Refer to: p9206, r9208
Description: Displays the value for the property set in p9206.
A value is only displayed for string type properties.
Dependency: Refer to: p9206, r9207
Note: An ASCII table (excerpt) can be found, for example, in the appendix to the List Manual.
Description: Sets the component number for a component to get its status LED to flash.
Dependency: Refer to: p9211
r9207 Topology direct access integer value / Topo access int
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
r9208[0...50] Topology direct access string / Topo access string
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
- - -
p9210 Flashing component number / Flash comp_no
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 499 0
