SINAMICS DCP
List Manual (LH21), 05/2016
15
2 Parameters
2.1 Overview of parameters
pxxxx[0...n] Parameter number
The parameter number is made up of a “p” or “r”, followed by the parameter number and the
index (optional).
Examples of the representation in the parameter list:
Other examples of the notation in the documentation:
The following applies to adjustable parameters:
The parameter value “when shipped” is specified under “Factory setting” with the relevant unit
in square parentheses. The value can be adjusted within the range defined by “Min” and “Max”.
The following applies to display parameters:
The fields “Min”, “Max” and “Factory setting” are specified with a dash “-” and the relevant unit
in square parentheses.
• p... Adjustable parameter (read and write parameter)
• r... Display parameters (read only)
• p0918 Adjustable parameter 918
• p0099[0...3] Adjustable parameter 99, indices 0 to 3
• p1001[0...n] Adjustable parameter 1001, indices 0 to n (n = configurable)
• r0944 Display parameter 944
• r2129.0...15 Display parameter 2129 with bit field from bit 0 (smallest bit) to bit 15
(largest bit)
• p1070[1] Adjustable parameter 1070, index 1
• p2098[1].3 Adjustable parameter 2098, index 1 bit 3
• r0945[2](3) Display parameter 945, index 2 of drive object 3
• p0795.4 Adjustable parameter 795, bit 4
Note
The parameter list can contain parameters that are not visible in the expert lists of the particular
commissioning software (e.g. parameters for trace functions).
The value for the factory setting can deviate from the value shown in the list as a result of
specific customer requirements.
