SINAMICS DCP
List Manual (LH21), 05/2016
19
2 Parameters
2.1 Overview of parameters
Function diagram
The parameter is included in this function diagram. The structure of the parameter function and
its relationship with other parameters is shown in the specified function diagram.
Parameter values
Description
Explanation of the function of a parameter.
Values
Lists the possible values of a parameter.
Table 2-2 Possible combinations of BICO interconnections
BICO input parameter
CI parameter BI parameter
BICO output parameter Unsigned32 /
Integer16
Unsigned32 /
Integer32
Unsigned32 /
FloatingPoint32
Unsigned32 /
Binary
CO: Unsigned8 x x – –
CO: Unsigned16 x x – –
CO: Integer16 x x r2050, r8850 –
CO: Unsigned32 x x – –
CO: Integer32 x x r2060, r8860 –
CO: FloatingPoint32 x x x –
BO: Unsigned8 – – – x
BO: Unsigned16 – – – x
BO: Integer16 – – – x
BO: Unsigned32 – – – x
BO: Integer32 – – – x
BO: FloatingPoint32 – – – –
Legend: x :
–:
rxxxx:
BICO interconnection permitted
BICO interconnection not permitted
BICO interconnection is only permitted for the specified CO parameters
Min. Minimum value of the parameter [unit]
Max Maximum value of the parameter [unit]
Factory setting Value when delivered [unit]
In the case of a binector/connector input, the signal source of the
default BICO interconnection is specified. A non-indexed connector
output is assigned the index [0].
