Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 9-77
Parts List
Parts List 13.2 Tray 1 (MPT) (2 of 5)
Item Description Part Number
1 Upper Frame Assembly (PL 13.3, page 9-79)
2 Lower Frame Assembly (PL 13.4, page 9-81)
3 Drive Bracket Assembly (items 4-13)
4Gear (27T)
5Nudger Cam
6Actuator
7Bracket
8Shaft
9Gear (20T)
10 Shaft
11 Gear (19T)
12 Bearing
13 Sleeve Bearing
14 Gear (29T/19T)
15 Gear (31T/15T)
16 MPT Feed/ Nudger Motor (items 17, 18)
17 Bracket
18 MPT Feed/ Nudger Motor (REP 13.3, page 8-132)
19 Sensor Bracket
20 MPT Nudger Position Sensor (REP 13.9, page 8-138) 930W00111
21 Top Cover (REP 13.5, page 8-134)
22 Actuator No Paper 120E29441
23 Harness Holder

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
