Revisions
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. B-3
Unrestricted Access Non-Confidential
Addition of note about configuring flash patch registers to be
present or not
FPB programmer’s model on page 11-6
First bullet point updated DWT on page 11-13
Addition of note about configuring DWT registers to be
present or not
Summary and description of the DWT registers on
page 11-13
DWT Control Register reset state updated DWT Control Register on page 11-15
DWT Control Register bit assignments updated Figure 11-5 on page 11-16 and Table 11-7 on page 11-16
Addition of note about configuring ITM registers to be
present or not
Summary and description of the ITM registers on
page 11-30
ITM Trace Control Register TSENA field bit function
updated
Table 11-22 on page 11-34
Addition of note about configuring AHB-AP registers to be
present or not
Summary and description of the AHB-AP registers on
page 11-39
AHB-AP Banked Data Register DATA field reset value
removed
Table 11-32 on page 11-43
Addition of information about absence of debug
functionality
About the DP on page 13-2
Information about exclusive memory accesses updated Exclusives on page 12-6 and Exclusives on page 12-7
Note about bit-band accesses updated Bit-band accesses on page 12-13
ETM block diagram updated Figure 14-1 on page 14-3
HCLK and CLK replaced by FCLK Table 14-2 on page 14-4, Table 14-3 on page 14-5,
Table 14-4 on page 14-5, Table 14-5 on page 14-6, and
Table 14-6 on page 14-6
Table B-1 Differences between issue E and issue F (continued)
Change Location
