ARM Cortex-M3 User Manual

Programmer’s Model
2-22 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Register byte [7:0] to register address immediate 8-bit offset,
postindexed
STRB.W <Rxf>, [<Rn>], #+/–<offset_8>
Register byte [7:0] to register address shifted by 0, 1, 2, or 3
places
STRB.W <Rxf>, [<Rn>, <Rm>{, LSL #<shift>}]
Store doubleword, preindexed STRD.W <Rxf>, <Rxf2>, [<Rn>, #+/–<offset_8> * 4]{!}
Store doubleword, postindexed STRD.W <Rxf>, <Rxf2>, [<Rn>, #+/–<offset_8> * 4]
Store register exclusive calculates an address from a base
register value and an immediate offset, and stores a word from
a register to memory if the executing processor has exclusive
access to the memory addressed.
STREX <c> <Rd>,<Rt>,[<Rn>{,#<imm>}]
Store register exclusive byte derives an address from a base
register value, and stores a byte from a register to memory if
the executing processor has exclusive access to the memory
addressed
STREXB <c> <Rd>,<Rt>,[<Rn>]
Store register exclusive halfword derives an address from a
base register value, and stores a halfword from a register to
memory if the executing processor has exclusive access to the
memory addressed.
STREXH <c> <Rd>,<Rt>,[<Rn>]
Register halfword [15:0] to register address + immediate 12-bit
offset
STRH.W <Rxf>, [<Rn>, #<offset_12>]
Register halfword [15:0] to register address shifted by 0, 1, 2,
or 3 places
STRH.W <Rxf>, [<Rn>, <Rm>{, LSL #<shift>}]
Register halfword [15:0] to register address immediate 8-bit
offset, preindexed
STRH{T}.W <Rxf>, [<Rn>, #+/–<offset_8>]{!}
Register halfword [15:0] to register address immediate 8-bit
offset, postindexed
STRH.W <Rxf>, [<Rn>], #+/–<offset_8>
Subtract immediate 12-bit value from register value SUB{S}.W <Rd>, <Rn>, #<modify_constant(immed_12)>
Subtract shifted register value from register value SUB{S}.W <Rd>, <Rn>, <Rm>{, <shift>}
Subtract immediate 12-bit value from register value SUBW.W <Rd>, <Rn>, #<immed_12>
Sign extend byte to 32 bits SXTB.W <Rd>, <Rm>{, <rotation>}
Sign extend halfword to 32 bits SXTH.W <Rd>, <Rm>{, <rotation>}
Table 2-5 32-bit Cortex-M3 instruction summary (continued)
Operation Assembler
