ARM Cortex-M3 User Manual

Programmer’s Model
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 2-21
Unrestricted Access Non-Confidential
Reverse bytes in each halfword REV16.W <Rd>, <Rn>
Reverse bytes in bottom halfword and sign-extend REVSH.W <Rd>, <Rn>
Rotate right by number in register ROR{S}.W <Rd>, <Rn>, <Rm>
Rotate right with extend RRX{S}.W <Rd>, <Rm>
Subtract a register value from an immediate 12-bit value RSB{S}.W <Rd>, <Rn>, #<modify_constant(immed_12)>
Subtract a register value from a shifted register value RSB{S}.W <Rd>, <Rn>, <Rm>{, <shift>}
Subtract immediate 12-bit value and C bit from register value
SBC{S}.W <Rd>, <Rn>, #<modify_constant(immed_12)>
Subtract shifted register value and C bit from register value SBC{S}.W <Rd>, <Rn>, <Rm>{, <shift>}
Copy selected bits to register and sign-extend SBFX.W <Rd>, <Rn>, #<lsb>, #<width>
Signed divide SDIV<c> <Rd>,<Rn>,<Rm>
Send event SEV<c>
Multiply signed words and add signed-extended value to
2-register value
SMLAL.W <RdLo>, <RdHi>, <Rn>, <Rm>
Multiply two signed register values SMULL.W <RdLo>, <RdHi>, <Rn>, <Rm>
Signed saturate SSAT.W <c> <Rd>, #<imm>, <Rn>{, <shift>}
Multiple register words to consecutive memory locations STM{IA|DB}.W <Rn>{!}, <registers>
Register word to register address + immediate 12-bit offset STR.W <Rxf>, [<Rn>, #<offset_12>]
Register word to register address immediate 8-bit offset,
postindexed
STR.W <Rxf>, [<Rn>], #+/–<offset_8>
Register word to register address shifted by 0, 1, 2, or 3 places STR.W <Rxf>, [<Rn>, <Rm>{, LSL #<shift>}]
Register word to register address immediate 8-bit offset,
preindexed Store, preindexed
STR.W <Rxf>, [<Rn>, #+/-<offset_8>]{!}
STRT.W <Rxf>, [<Rn>, #<offset_8>]
Register byte [7:0] to register address immediate 8-bit offset,
preindexed
STRB{T}.W <Rxf>, [<Rn>, #+/–<offset_8>]{!}
Register byte [7:0] to register address + immediate 12-bit
offset
STRB.W <Rxf>, [<Rn>, #<offset_12>]
Table 2-5 32-bit Cortex-M3 instruction summary (continued)
Operation Assembler

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
