Table 57 CRIMP TOOLS FOR BACT12AV AND AMP SOLID NICKEL TERMINAL LUGS (Continued)
Crimp Barrel
Size
Wire Size
Crimp Tool
Basic Unit Holder Cam Head Die
16-14 16-14
189721-1
(Battery powered)
356302-1 - 356744-2 -
189721-1
(Battery powered)
356303-1 356438-1 1213850-2 -
314590-() - - - 314543-1
314590-() - - - 314543-2
314700-() - - - 314543-1
314700-() - - - 314543-2
46988 - - - -
59294-() - - - -
69010 - - 45176 -
12-10 12-10
1901235-3
(Battery powered)
- - 59461 -
314937-1 - - - 314915-1
59461 - - - -
PHRPU2 - - PHST-59461 -
NOTE: Refer to Subject 20-30-22 for the assembly of a terminal lug with a conductor that is smaller
than the crimp barrel size of the terminal lug.
(1) Make a selection of a terminal lug from Table 20.
NOTE: A BACT12AV or an AMP solid nickel terminal lug is a satisfactory alternative to a
BACT12M terminal lug.
NOTE: For the selection of the terminal, use:
• The crimp barrel size, if one wire is to be terminated
• The CAU range, if more than one wire is to be terminated.
NOTE: Refer to Subject 20-30-22 if more than one wire is to be terminated.
(2) Make a selection of a crimp tool from Table 57.
(3) If the tool has an insulation crimp adjustment, set the position of the adjustment. Refer to
Paragraph 2.B.
Make sure to set the adjustment at position 2 for these wires:
• Champlain 24-00034 wire
• Champlain 24-00523 wire
• Filotex 85842 wire.
(4) Remove the necessary length of the insulation from the end of the wire.
Refer to:
• Figure 22
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 71
Feb 15/2016D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
