PARAGRAPH PAGE
6. UNSEALED BUTT SPLICE CONFIGURATIONS (continued) 66
D. Unsealed Butt Splice Configurations - One Wire to One Wire - Butt Splice, Sleeves 73
E. Unsealed Butt Splice Configurations - More Than One Wire to More Than One Wire -
Butt Splice, Sleeves 76
7. SEALED SPLICE CONFIGURATIONS FOR UNSHIELDED WIRES AND UNSHIELDED CABLES
79
A. Splice Assembly Configurations 79
B. Sealed Splice Configurations for Unshielded Wires and Cables - One Wire to One Wire -
Tape, Ties 80
C. Sealed Splice Configurations for Unshielded Wires and Cables - One Wire to One Wire -
Sealant, Sleeve, Ties 84
D. Sealed Splice Configurations for Unshielded Wires and Cables - One Wire to Two Wires
- Tape, Ties 88
E. Sealed Splice Configurations for Unshielded Wires and Cables - Two Wires to Two
Wires - Tape, Ties 92
F. Sealed Splice Configurations for Unshielded Wires and Cables - One Wire to Two Wires
- D-436-58 Splice Kit - Wires from Both Ends of the Splice 96
G. Sealed Splice Configurations for Unshielded Wires and Cables - One or Two Wires to
One or Two Wires - Splice Kit 98
H. Sealed Splice Configurations for Unshielded Wires and Cables - One or Two Wires to
One or Two Wires - Sleeve 101
I. Sealed Splice Configurations for Unshielded Wires and Cables - One to Five Wires to
One to Five Wires - Splice Kit 105
J. Sealed Splice Configurations for Unshielded Wires and Cables - One to Five Wires to
One to Five Wires - Sleeve 108
K. Sealed Splice Configurations for Unshielded Wires and Cables - One Cable to One
Cable - Tape, Ties 113
L. Sealed Splice Configurations for Unshielded Wires and Cables - One Cable to One
Cable - Tape, Sleeve 115
M. Sealed Splice Configurations for Unshielded Wires and Cables - In-Line Resistor and
Diode 117
8. SEALED SPLICE CONFIGURATIONS FOR UNSHIELDED WIRES AND UNSHIELDED CABLES
FOR HIGH TEMPERATURE 119
A. Splice Assembly Configurations 119
B. Sealed Splice Configurations for Unshielded Wires and Cables for High Temperature -
One Wire to One Wire - Tape, Ties 120
C. Sealed Splice Configurations for Unshielded Wires and Cables for High Temperature -
One Wire to One Wire - Tape, Sleeve 124
D. Sealed Splice Configurations for Unshielded Wires and Cables for High Temperature -
One Wire to Two Wires - Tape, Ties 128
E. Sealed Splice Configurations for Unshielded Wires and Cables for High Temperature -
One Wire to Two Wires - Tape, Sleeve 133
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 2
Jun 15/2021D6-54446
