11. SEALED SPLICE CONFIGURATIONS WITH MECHANICAL FERRULES FOR SHIELDED WIRE
AND SHIELDED CABLE FOR HIGH TEMPERATURE 201
A. Splice Assembly Configurations 201
B. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Wire to One Shielded Wire - Mechanical Ferrules, Tape, Ties 202
C. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Wire to One Shielded Wire - Mechanical Ferrules, Tape, Sleeve 205
D. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Wire to Two Shielded Wires - Mechanical Ferrules, Tape, Ties 208
E. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Wire to Two Shielded Wires - Mechanical Ferrules, Tape, Sleeve 213
F. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - Two
Shielded Wires to Two Shielded Wires - Mechanical Ferrules, Tape, Ties 218
G. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - Two
Shielded Wires to Two Shielded Wires - Mechanical Ferrules, Tape, Sleeve 222
H. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Cable to One Shielded Cable - Mechanical Ferrules, Tape, Ties 226
I. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Cable to One Shielded Cable - Mechanical Ferrules, Tape, Sleeve 229
12. SEALED SPLICE CONFIGURATIONS WITH SHIELD-KONS FOR SHIELDED WIRE AND
SHIELDED CABLE 232
A. Splice Assembly Configurations 232
B. Sealed Splice Configurations for Shielded Wire and Cable - One Shielded Wire to One
Shielded Wire - Shield Kons, Tape, Ties 232
C. Sealed Splice Configurations for Shielded Wire and Cable - One Shielded Wire to One
Shielded Wire - Shield Kons, Tape, Sleeve 236
D. Sealed Splice Configurations for Shielded Wire and Cable - One Shielded Cable to One
Shielded Cable - Shield Kons, Tape, Ties 241
E. Sealed Splice Configurations for Shielded Wire and Cable - One Shielded Cable to One
Shielded Cable - Shield Kons, Tape, Sleeve 245
13. SEALED SPLICE CONFIGURATIONS WITH SHIELD TERMINATION RINGS AND SHIELD
TERMINATOR BANDS FOR SHIELDED WIRE AND SHIELDED CABLE FOR HIGH
TEMPERATURE 249
A. Splice Assembly Configurations 249
B. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Wire to One Shielded Wire - Shield Termination Rings, Shield Terminator
Bands, Tape, Ties 250
C. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Wire to One Shielded Wire - Shield Termination Rings, Shield Terminator
Bands, Tape, Sleeve 261
D. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - One
Shielded Cable to One Shielded Cable - Shield Termination Rings, Shield Terminator
Bands, Tape, Ties 271
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 4
Jun 15/2021D6-54446
