Spanning-Tree Commands 371
Port 4 (1/4) enabled
State: Blocking Role: Alternate
Port Identifier: 128.4 Port cost: 20000
Type: Shared (configured: auto) STP Port Fast: No (configured:no)
Designated bridge Priority: 28672 Address: 00:30:94:41:62:c8
Designated port id: 128.25 Designated path cost: 20000
Guard root:Disabled
Number of transitions to forwarding
state: 1
BPDU: sent 2, received 120638
Port 5 (1/5) enabled
State: Disabled Role: N/A
Port id: 128.5 Port cost: 20000
Type: N/A (configured: auto) Port Fast: N/A (configured:no)
Designated bridge Priority: N/A Address: N/A
Designated port id: N/A Designated path cost: N/A
Guard root:Disabled
Number of transitions to forwarding
state: N/A
BPDU: sent N/A, received N/A
Console# show spanning-tree mst-configuration
Name: Region1
Revision: 1
Instance Vlans Mapped State
0 1-9,21-4094 Enabled
1 10-20 Enabled
